Electric Walkie Stacker 1500kg Load Capacity Adjustable Straddle Leg

Place of Origin : Jiangsu, China, CN;JIA

Brand Name : KAD

MOQ : 1

Price : $1,280-1,680

Fork Length : 1220mm, 1150MM

Fork Width : 550/680mm

Load Center : 500mm

Weight With Battery : 480/495/515/535KG

Load Weight : 1500KG

Load Height : 500mm

Battery Capacity : 24/80Ah

Power Source : DC MOTOR

Lifting Height : 1600/2000/2500/3000/4000MM

Lowest Mast : 2080/1580/1830/2080/1580MM

Max Operating Height : 2080/2730/3230/3730/4750MM

Min Fork Height : ≤90MM

Driving Speed : 5.0/5.0 MM/S

Lifting Speed : 140/135 MM/S

Descending Speed : 150/155 MM/S

Contact Now

Full Electric Walkie Pedestrian Stacker with Adjustable Straddle Leg Forged Forks 1000kg 1500kg 3000mm 4000mm Gel AGM Battery

The Adjustable Full Electric Walkie Stacker with is a versatile and efficient material handling solution designed for various industrial and warehouse applications. Its key advantage lies in its adjustable widening legs, providing enhanced stability and safety when lifting and transporting heavy loads. This feature makes it ideal for uneven or narrow spaces where traditional forklifts may struggle.

MODEL					CDDW10 CDDW15
Features	Drive system			Battery
	Features	Driving mode			Walkie
		Load Capacity	Q	KG	1500
		Load Center	C	MM	500
Weight	Weight(With battery)		KG	480/495/515/535
Wheels	Material			PU
Size	Lifting Height	H3	MM	1600/2000/2500/3000/4000
		Lowest Mast	H1	MM	2080/1580/1830/2080/1580
		Max.Height when operating	H4	MM	2080/2730/3230/3730/4750
		Min.Height of Fork	H13	MM	≤90
		Length	L1	MM	1770
		Width	B1	MM	850
	Size	Fork Length	L	MM	1070
		Wheelbase	Y	MM	1250
		Fork Outside Width	B5	MM	680
		Fork Inside Width		MM	305
		Min.Turning Radius	WA	MM	1390
Performance	Driving Speed （Empty/Full Load）		MM/S	5.0/5.0
		Lifting Speed （Empty/Full Load）		MM/S	140/135
		Descending Speed （Empty/Full Load）		MM/S	150/155
		Max.Gradient （Empty/Full Load）		°	7/5
		Brake			Electromagnetic brake
	Driving Motor		KW	DC/0.75
		Lifting Motor		KW	DC/2.2
Battery	Capacity		V/Ah	24/80/100;Li/gel

Electric Walkie Stacker 1500kg Load Capacity Adjustable Straddle Leg

Main Features

1) Using Curtis controller,which can be serviced by any forklift service company around the world.

2) With its integrated charger it gives you the flexibility you need in a modern, urban supply chain.

3) Maintenance-free batteries,no need to add water.

4)High strength fork

Main Parts

Name: Control Handle

Brand: KAD

Domestic famous control handle,functional buttons, can control UP/DOWN, FORWARD/BACKWARD sensitively. Using Curtis brand accelerator to ensure the safe operating.

Night operation lights

It can play a great role in warehouses with insufficient lighting.

Reverse rearview mirror and buzzing sound.

Some companies, in order to save costs, do not install this safety device on walkie stacker. We
have added safety devices while ensuring a price advantage.

Durable mast

High strengthen durable mast, which is 3-stage and support heavy load at 4-4.5m

Q1. What is your terms of packing? A: Generally, we pack our goods in paper package and Iron pallet. We can pack the goods in your branded boxes after getting your authorization letters. Q2. What is your terms of payment? A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance. Or As negotiated Q3. What is your terms of delivery? A: EXW, FOB, CFR, CIF, DDU. Q4. How about your delivery time? A: Generally, it will take 5 to 30 days after receiving your deposit. The specific delivery time depends on the items and the quantity of your order. Q5. Do you test all your goods before delivery? A: Yes, we have 100% test before delivery Q6: How do you make our business long-term and good relationship? 1. We keep good quality and competitive price to ensure our customers benefit ; 2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
